Locking Devices, TwistLock, Industrial, Female Connector Body, 30A 3-Phase Wye 277/480V AC, 4-Pole 5-Wire Grounding, L22-30R, Screw Terminal, Black and White

Specifications

Insulation Insulated Body
Item Type Insulgrip Connector
Number of Poles 4-Pole
OEM Brand Name Hubbell Wiring Device-Kellems
Performance
  • Electrical - Current Interrupting - Certified for current  interrupting at full rated current
  • Electrical - Dielectric Voltage - Withstands 2,000V minimum
  • Environmental - Flammability - HB or better per UL94 or CSA 22.2 No.0.6
  • Environmental - Operating Temperatures - Maximum Continuous 75°C Minimum -40°C (w/o impact)
  • Mechanical - Terminal Accomodation - #16 AWG - #8 AWG stranded copper wire only.
  • Mechanical - Terminal Identification - Terminals identified in accordance with UL 498
Type Connector Body
UPC  783585039701
Display Size Standard
Height 2.33 in
Length 3.86 in
Weight 0.40 Ib
Width 2.33 in
Amperage Rating 30 A
Connectivity Pressure Screw Terminal
Current/Amperage Rating 30 A
Dielectric Strength Withstands 2,000V minimum
Phase 3 Phase WYE
Voltage Rating 3 Phase WYE 277/480 VAC
Number of WIres 5-Wire
Nema Rating L22-30R
